Automotive

Amphenol offers a broad array of innovative automotive-grade interconnect solutions from wire-to-board, board-to-board, input-output, power management, to FFC-FPC connectors.

  • Our rigorously tested connectors perform to automotive standards
  • We provide customized connector solutions in addition to the existing portfolio of modular connector systems

FEATURED RESOURCES
CONTACT US

Working closely with the automotive industry, Amphenol brings a broad array of innovative technology and solutions to support the growth in the automotive industry, particularly in plating, signal integrity performance, and power management.

As automobiles utilize more electronic components and head towards being a total autonomous operation, the key differentiator between suppliers will be their quality, capabilities, and performance. Amphenol has the global quality, disciplines, and commitment to meet the demands and requirements of all these new technologies.

Automotive

EV Charging

With a wide portfolio of power products supporting 15A-1000A ratings, low contact resistance, high thermal support and component modularity, Amphenol offers the most efficient solutions for the modern EV charging station. Our energy efficient connectivity extends from level 2 chargers to Level 3 Super-fast chargers capable of charging an EV battery in less than 30 minutes, in addition to IP67 sealed connectivity for underground wireless charging.

Level 2 EV Charger

Level 2 EV chargers are capable of charging a 40kWh battery in 3-7 hours and 75kWh battery in 5-11 hours. Amphenol provides energy efficient, high power connectors that go to into the power module boards of these charging stations.

Featured Products

  • 48V BarKlip® BK500 IO for EV Charging
    Amphenol's 48V Barklip® BK500 power cable assemblies are designed to provide a convenient method of distributing up to 500A per contact between busbars, cables, and circuit boards. The connector system features two individual power circuits and two newly added secondary chassis grounding contacts.
    DETAILS
  • PwrBlade+® Connector
    The PwrBlade+® connector is a next generation AC/DC power distribution connector system for demanding applications requiring higher linear current density and low power loss.
    DETAILS
  • PwrBlade+® Cable Assembly
    PwrBlade+® cable connectors offer flexibility to meet a wide variety of customer needs. The connectors come in both Cable-To-Cable and Cable-To-Board solutions.
    DETAILS
  • BarKlip® XP Connectors
    Amphenol's BarKlip® XP connectors feature independent points of contacts that provide overall lower resistance and greater overall efficiency.
    DETAILS
  • BarKlip® BK200 I/O
    Amphenol's BarKlip® BK200 I/O provides a convenient method of distributing up to 200A between busbars, cables and circuit boards.
    DETAILS
  • Minitek® Pwr 3.0 HCC
    Minitek® Pwr 3.0 High Current Connector (HCC) is designed for power applications with current rating up to 12A per contact and wire gauge range from 30 to 16AWG for Wire-to-Wire and Wire-to-Board applications.
    DETAILS
  • CoolPower® Slim Drawer
    Amphenol's CoolPower® Slim Drawer Series is configurable to accommodate various combinations of power and signal contacts and a number of mounting and termination options.
    DETAILS
  • CoolPower® SDM Connectors
    CoolPower® Slim Drawer Mini (SDM) Connectors offer a high level of mating configuration flexibility, current density, and a thin profile making it ideal for compact board-to-­board power interconnects.
    DETAILS
  • EazyPwr™ IP67 Field Installable
    EazyPwr™ IP67 field installable connector provides the next generation of custom power with up to 125A per contact. The metal latching system ensures a reliable connection between the mated pair.
    DETAILS
  • PwrBlade® Connector
    The PwrBlade® power distribution connector system from Amphenol includes power and signal contacts to provide power distribution and power control in a single connector.
    DETAILS
  • PwrBlade® Cable Assembly
    The PwrBlade® cable connectors are designed to mate to PwrBlade® right-angle or vertical board-mounted headers. By expanding beyond board-to-board applications, designers can now connect power supplies and power distribution subassemblies in a wider range of applications.
    DETAILS
  • BarKlip® BK100 I/O
    Amphenol's BarKlip® BK100 I/O provides a convenient method of distributing up to 100A between busbars, cables and circuit boards.
    DETAILS
  • PwrBlok® Connectors
    PwrBlok® connectors provide a high current power interconnection with quick connect/disconnect function for space constrained board-to-board, board-to-busbar, and busbar-to-busbar power distribution applications.
    DETAILS
  • SheerPwr® Circular Connectors
    SheerPwr® Circular is a high-current, low-resistance interface, designed for applications connecting busbars -to-busbars, busbars-to-boards and board-to-board configurations.
    DETAILS

Level 3 EV Charger

Level 3 EV chargers are high performing super speed chargers capable of charging 40kWh battery in just 30 minutes and 75kWh in less than 2 hours. Amphenol provides enhanced power connectors to go into power modules and bus bars that meet current and voltage ratings of 100A and 480V.

Featured Products

  • 48V BarKlip® BK500 IO for EV Charging
    Amphenol's 48V Barklip® BK500 power cable assemblies are designed to provide a convenient method of distributing up to 500A per contact between busbars, cables, and circuit boards. The connector system features two individual power circuits and two newly added secondary chassis grounding contacts.
    DETAILS
  • PwrBlade® ULTRA Connector®
    The PwrBlade® ULTRA connector is the newest addition to the PwrBlade® product line. This new design offers an overall height reduction of 24% to reduce airflow impedance in high density power supplies.
    DETAILS
  • PwrBlade® Connector
    The PwrBlade® power distribution connector system from Amphenol includes power and signal contacts to provide power distribution and power control in a single connector.
    DETAILS
  • PwrBlade+® Connector
    The PwrBlade+® connector is a next generation AC/DC power distribution connector system for demanding applications requiring higher linear current density and low power loss.
    DETAILS
  • BarKlip® BK200 I/O
    Amphenol's BarKlip® BK200 I/O provides a convenient method of distributing up to 200A between busbars, cables and circuit boards.
    DETAILS
  • PwrBlok® Connectors
    PwrBlok® connectors provide a high current power interconnection with quick connect/disconnect function for space constrained board-to-board, board-to-busbar, and busbar-to-busbar power distribution applications.
    DETAILS
  • SheerPwr® Circular Connectors
    SheerPwr® Circular is a high-current, low-resistance interface, designed for applications connecting busbars -to-busbars, busbars-to-boards and board-to-board configurations.
    DETAILS
  • BarKlip® XP Connectors
    Amphenol's BarKlip® XP connectors feature independent points of contacts that provide overall lower resistance and greater overall efficiency.
    DETAILS
  • BarKlip® BK100 I/O
    Amphenol's BarKlip® BK100 I/O provides a convenient method of distributing up to 100A between busbars, cables and circuit boards.
    DETAILS

Combined Charging System

The combined charging system (CCS) combines AC and fast-charging DC in a common large plug. They will have AC Type 1 and Type 2 connectors along with two extra pins at the bottom for DC charging. They are generally called Combo 1 and Combo 2, respectively. The CCS allows for faster and more efficient charging along with space-saving compared to other prominent protocols in the market. Amphenol provides an array of high-power high performing connectors for CCS.

Featured Products

  • 48V BarKlip® BK500 IO for EV Charging
    Amphenol's 48V Barklip® BK500 power cable assemblies are designed to provide a convenient method of distributing up to 500A per contact between busbars, cables, and circuit boards. The connector system features two individual power circuits and two newly added secondary chassis grounding contacts.
    DETAILS
  • BarKlip® BK200 I/O
    Amphenol's BarKlip® BK200 I/O provides a convenient method of distributing up to 200A between busbars, cables and circuit boards.
    DETAILS
  • PwrBlade+® Connector
    The PwrBlade+® connector is a next generation AC/DC power distribution connector system for demanding applications requiring higher linear current density and low power loss.
    DETAILS
  • PwrBlade+® Cable Assembly
    PwrBlade+® cable connectors offer flexibility to meet a wide variety of customer needs. The connectors come in both Cable-To-Cable and Cable-To-Board solutions.
    DETAILS
  • Minitek® Pwr 3.0 HCC
    Minitek® Pwr 3.0 High Current Connector (HCC) is designed for power applications with current rating up to 12A per contact and wire gauge range from 30 to 16AWG for Wire-to-Wire and Wire-to-Board applications.
    DETAILS
  • BarKlip® XP Connectors
    Amphenol's BarKlip® XP connectors feature independent points of contacts that provide overall lower resistance and greater overall efficiency.
    DETAILS
  • CoolPower® Slim Drawer
    Amphenol's CoolPower® Slim Drawer Series is configurable to accommodate various combinations of power and signal contacts and a number of mounting and termination options.
    DETAILS
  • CoolPower® SDM Connectors
    CoolPower® Slim Drawer Mini (SDM) Connectors offer a high level of mating configuration flexibility, current density, and a thin profile making it ideal for compact board-to-­board power interconnects.
    DETAILS
  • EazyPwr™ IP67 Field Installable
    EazyPwr™ IP67 field installable connector provides the next generation of custom power with up to 125A per contact. The metal latching system ensures a reliable connection between the mated pair.
    DETAILS
  • PwrBlade® Cable Assembly
    The PwrBlade® cable connectors are designed to mate to PwrBlade® right-angle or vertical board-mounted headers. By expanding beyond board-to-board applications, designers can now connect power supplies and power distribution subassemblies in a wider range of applications.
    DETAILS
  • SheerPwr® Circular Connectors
    SheerPwr® Circular is a high-current, low-resistance interface, designed for applications connecting busbars -to-busbars, busbars-to-boards and board-to-board configurations.
    DETAILS
  • PwrBlok® Connectors
    PwrBlok® connectors provide a high current power interconnection with quick connect/disconnect function for space constrained board-to-board, board-to-busbar, and busbar-to-busbar power distribution applications.
    DETAILS

Superfast Charger

The quick charging Super-Fast Chargers save on time by giving the EV the quickest boost. Amphenol’s busbar connector and cable solutions are ultrasonically welded and provide current carrying capacity up to 200A/contact to the heavy-duty AC/DC power inverters.

Featured Products

  • 48V BarKlip® BK500 IO for EV Charging
    Amphenol's 48V Barklip® BK500 power cable assemblies are designed to provide a convenient method of distributing up to 500A per contact between busbars, cables, and circuit boards. The connector system features two individual power circuits and two newly added secondary chassis grounding contacts.
    DETAILS
  • BarKlip® BK200 I/O
    Amphenol's BarKlip® BK200 I/O provides a convenient method of distributing up to 200A between busbars, cables and circuit boards.
    DETAILS
  • PwrBlok® Connectors
    PwrBlok® connectors provide a high current power interconnection with quick connect/disconnect function for space constrained board-to-board, board-to-busbar, and busbar-to-busbar power distribution applications.
    DETAILS
  • SheerPwr® Circular Connectors
    SheerPwr® Circular is a high-current, low-resistance interface, designed for applications connecting busbars -to-busbars, busbars-to-boards and board-to-board configurations.
    DETAILS
  • PwrBlade® ULTRA Connector®
    The PwrBlade® ULTRA connector is the newest addition to the PwrBlade® product line. This new design offers an overall height reduction of 24% to reduce airflow impedance in high density power supplies.
    DETAILS
  • PwrBlade® Connector
    The PwrBlade® power distribution connector system from Amphenol includes power and signal contacts to provide power distribution and power control in a single connector.
    DETAILS
  • PwrBlade+® Cable Assembly
    PwrBlade+® cable connectors offer flexibility to meet a wide variety of customer needs. The connectors come in both Cable-To-Cable and Cable-To-Board solutions.
    DETAILS

Wireless EV Charger

Wireless EV charging systems situated underground can charge the EV parked above through induction technology. Amphenol promises sealed high power solutions with IP67 specifications that are custom designed for the charger cabinets often prone to harshest of weather conditions.

Featured Products

  • EazyPwr™ IP67 Field Installable
    EazyPwr™ IP67 field installable connector provides the next generation of custom power with up to 125A per contact. The metal latching system ensures a reliable connection between the mated pair.
    DETAILS
  • PwrBlade+® Cable Assembly
    PwrBlade+® cable connectors offer flexibility to meet a wide variety of customer needs. The connectors come in both Cable-To-Cable and Cable-To-Board solutions.
    DETAILS
  • PwrBlade® Cable Assembly
    The PwrBlade® cable connectors are designed to mate to PwrBlade® right-angle or vertical board-mounted headers. By expanding beyond board-to-board applications, designers can now connect power supplies and power distribution subassemblies in a wider range of applications.
    DETAILS

Automotive Lighting

Modern automobiles are rich with ADAS features like smart LED lighting for adaptive headlights, and superior interior lighting. Amphenol provides a range of advanced USCAR2 compliant connectors like Minitek Microspace™, which are compact and meet LV214 standards.
Featured Products

Advanced Electronics Systems

Amphenol brings a broad array of innovative technology and solutions to support the growth in the automotive industry, particularly in plating, signal integrity performance, and power management. As automobiles become more ADAS rich and head towards being a total autonomous operation, the key differentiator between suppliers will be their quality, capabilities and performance. Amphenol has the global quality, disciplines, and commitment to meet the demands and requirements of all these new technologies.

Advanced driver-assistance systems (ADAS) are electronic systems in a vehicle that use advanced technologies to assist the driver on safety and comfort aspects. As vehicles take on more ADAS features, this has created a growing demand for automotive connectors to be more reliable, compact and to deliver high speed data transmission.

  • NETBridge+™ Automotive Ethernet Connector System
    NETBridge+™ Automotive Ethernet Connector System is designed for automotive applications and can transmit up to 100Mb/s and 1Gb/s according to IEEE 100BASE-T1 and 1000BASE-T1 and will be upgraded to 10Gb/s.
    DETAILS
  • HSBridge+ Connector System
    HSBridge+ connectors come with automotive grade USB Type C interface. These connectors have headers compliant to USCAR-30 USB and are performance tested according to USCAR-2.
    DETAILS
  • FlexLock® 2.54mm FPC-to-Board Connectors
    FlexLock® 2.54mm FPC-to-Board connectors are designed to address the growing demands of the automotive market.
    DETAILS
  • 0.50mm Power Pin Floating Board-to-Board
    Power pin 0.50mm pitch floating board-to-board connector system is designed for applications that need large current and space saving.
    DETAILS
  • HSD (High Speed Data) Connector System
    HSD connector system is a fully shielded interconnect system that can be used with shielded twisted quad cables. It has a high-performance digital system for low-voltage differential signals which prevents interference from crosstalk and external sources.
    DETAILS
  • HSC Connector System
    HSC connector system is a fully shielded interconnect system that supports data rates up to 1Gb/s and more. With 0.50mm square terminals, it allows a lighter and smaller connector design.
    DETAILS
  • BergStak® FX10 0.50mm Board-to-Board
    FCI Basics BergStak® product range is expanded to include 0.50mm BergStak® FX10 board-to-board connector known for its fast data transmission and high signal quality.
    DETAILS
  • 0.80mm Floating Board-to-Board Connectors - B406/B407/B410 Series
    Amphenol's B406/B407/B410 series are 0.80mm pitch floating board-to-board connectors which support stack height up to 23mm and positions from 30 to 120.
    DETAILS
  • BergStak® 0.50mm Self-Alignment Board-to-Board
    FCI Basics BergStak® 0.50mm self-alignment connectors come with a stack height of 3mm and 50 positions extendable across 20 to 60 positions in increments of 10.
    DETAILS
  • BergStak® 0.40mm Self-Alignment Board-to-Board
    FCI Basics BergStak® 0.40mm self-alignment connectors come with a stack height of 3.50mm and 30 positions extendable up to 10 to 60 positions with 10 positions incremental.
    DETAILS
  • Minitek127® 1.27mm Board-to-Board
    FCI Basics Minitek127® standard board-to-board connector is the improved 1.27mm pitch modular system.
    DETAILS
  • BergStak® 0.80mm Pitch
    FCI Basics BergStak® 0.8mm is a flexible solution designed for high speed and high density, parallel board-to-board connector system with 16 PCB stack heights in 9 sizes up to 200 positions.
    DETAILS
  • MEG-Array® R+
    Leveraging proven technologies, including an industry leading BGA design, offering superior self-aligning and self-leveling.
    DETAILS
  • MEG-Array®
    The MEG-Array® Mezzanine Connector system provides the high density and high-speed benefits of a large array supported by the reliability and low costs of standard surface mount PCB assembly.
    DETAILS
  • BergStik® 2.54mm
    BergStik® FCI Basics 2.54mm unshrouded headers are available in surface-mount (SMT), through-hole (THT), press-fit, stacking and pin-in-paste (PIP) versions.
    DETAILS
  • Minitek® 2.00mm
    Minitek® is Amphenol's brand for board to board and wire/cable to board connectors in 2.00mm pitch. It is a fully modular system enabling all types of connections between PCBs, wires and flat cables.
    DETAILS
  • Minitek MicroSpaceXS™ Waterproof 1.27mm Crimp-to-Wire
    Minitek MicroSpaceXS™ Waterproof Crimp-to-Wire connector platform's unique design is compatible to LV214 Severity-3 and USCAR-T2V2 specifications.
    DETAILS
  • Minitek MicroSpace™ 1.27mm Crimp-to-Wire
    FCI Basics Minitek MicroSpace™ Crimp-to-Wire connector platform's unique design enables LV214 Severity-2 and performs at 1.8, 1.5 and 1.27mm pitch.
    DETAILS
  • Minitek MicroSpace™ 1.50mm Crimp-to-Wire
    FCI Basics Minitek MicroSpace™ Crimp-to-Wire connector platform's unique design enables LV214 Severity-2 and performs at 1.8, 1.5 and 1.27mm pitch.
    DETAILS
  • Minitek MicroSpace™ 1.80mm Crimp-to-Wire
    FCI Basics Minitek MicroSpace™ Crimp-to-Wire connector platform's unique design enables LV214 Severity-2 and performs at 1.8, 1.5 and 1.27mm pitch.
    DETAILS
  • 0.50mm FFC/FPC Connectors with Autolock Mechanism - F308/F332 Series
    F308/F332 series is a 0.50mm pitch right angle Non-ZIF flex connector with an auto lock mechanism and surface mount termination. It features a height of 2.45mm and comes in 6 to 68 contacts.
    DETAILS
  • 0.50mm FFC/FPC Connectors
    Amphenol's 0.50mm pitch flex connectors utilize 0.50mm contact spacing to terminate mobile devices across a variety of applications.
    DETAILS
  • 1.00mm FFC/FPC Connectors
    Amphenol's 1.00mm pitch flex connectors utilize 1.00mm contact spacing to terminate displays and support complex board-to-board connections.
    DETAILS
  • High-Speed Flex Connectors
    FCI Basics High-Speed flex connectors can transfer data rates up to 10Gb/s. It has a 0.30mm pitch, in-line layout and backflip actuator coupled with locking feature for strong FPC retention.
    DETAILS

Automotive Ethernet

Amphenol automotive Ethernet connectors are designed for the automotive environment, support all current IEEE Automotive Ethernet Standards, and are developed in accordance with USCAR-2, VDAAK LV214, and ISO 8092.

Featured Products

  • Ve-NET™ Automotive Multigigabit Differential Connector System
    Automotive-grade Ethernet solution developed according to USCAR-2 & LV214, along with miniaturized and various sealed/non-sealed configurations; Featured high data rates up to 50Gbps per port and highly compact and robust to fulfill automotive applications such as camera systems, ADAS, and Autonomous Driving. Supports Automotive Ethernet, LVDS, APIX 3 and FPD4.
    DETAILS
  • NETBridge+™ Automotive Ethernet Connector System
    NETBridge+™ Automotive Ethernet Connector System is designed for automotive applications and can transmit up to 100Mb/s and 1Gb/s according to IEEE 100BASE-T1 and 1000BASE-T1 and will be upgraded to 10Gb/s.
    DETAILS
  • NETBridge™ Automotive Ethernet Connector
    NETBridge™ Automotive Ethernet Connector System is designed for the automotive environment and can transmit up to 100Mbit/s and 1Gbit/s according to IEEE 100BASE-T1 and 1000BASE-T1.
    DETAILS

Infotainment and Navigation

Amphenol provides a range of connectors for automotive infotainment and navigation applications such as Telematics, multimedia, GPS, navigation and camera components.

Featured Products

  • 0.50mm Power Pin Floating Board-to-Board
    Power pin 0.50mm pitch floating board-to-board connector system is designed for applications that need large current and space saving.
    DETAILS
  • 2.00mm FFC/FPC connectors with Autolock Mechanism
    Non-ZIF flex connector with an autolock mechanism and surface mount termination. F73W is a vertical connector with height of 6.25mm while F73V is right angle connector with height of 3.00mm.
    DETAILS
  • NETBridge+™ Automotive Ethernet Connector System
    NETBridge+™ Automotive Ethernet Connector System is designed for automotive applications and can transmit up to 100Mb/s and 1Gb/s according to IEEE 100BASE-T1 and 1000BASE-T1 and will be upgraded to 10Gb/s.
    DETAILS
  • HSBridge+ Connector System
    HSBridge+ connectors come with automotive grade USB Type C interface. These connectors have headers compliant to USCAR-30 USB and are performance tested according to USCAR-2.
    DETAILS
  • HSD (High Speed Data) Connector System
    HSD connector system is a fully shielded interconnect system that can be used with shielded twisted quad cables. It has a high-performance digital system for low-voltage differential signals which prevents interference from crosstalk and external sources.
    DETAILS
  • HSC Connector System
    HSC connector system is a fully shielded interconnect system that supports data rates up to 1Gb/s and more. With 0.50mm square terminals, it allows a lighter and smaller connector design.
    DETAILS
  • FLTStack 0.50mm Floating Board-to-Board
    FLTStack 0.50mm is a floating type Board-to-Board (BTB) connector designed to operate a minimum of ±0.50mm floating range in the XY directions.
    DETAILS
  • BergStak® FX10 0.50mm Board-to-Board
    FCI Basics BergStak® product range is expanded to include 0.50mm BergStak® FX10 board-to-board connector known for its fast data transmission and high signal quality.
    DETAILS
  • 0.80mm Floating Board-to-Board Connectors - B406/B407/B410 Series
    Amphenol's B406/B407/B410 series are 0.80mm pitch floating board-to-board connectors which support stack height up to 23mm and positions from 30 to 120.
    DETAILS
  • BergStak® 0.50mm Self-Alignment Board-to-Board
    FCI Basics BergStak® 0.50mm self-alignment connectors come with a stack height of 3mm and 50 positions extendable across 20 to 60 positions in increments of 10.
    DETAILS
  • BergStak® 0.40mm Self-Alignment Board-to-Board
    FCI Basics BergStak® 0.40mm self-alignment connectors come with a stack height of 3.50mm and 30 positions extendable up to 10 to 60 positions with 10 positions incremental.
    DETAILS
  • Minitek127® 1.27mm Board-to-Board
    FCI Basics Minitek127® standard board-to-board connector is the improved 1.27mm pitch modular system.
    DETAILS
  • BergStak® 0.80mm Pitch
    FCI Basics BergStak® 0.8mm is a flexible solution designed for high speed and high density, parallel board-to-board connector system with 16 PCB stack heights in 9 sizes up to 200 positions.
    DETAILS
  • MEG-Array® R+
    Leveraging proven technologies, including an industry leading BGA design, offering superior self-aligning and self-leveling.
    DETAILS
  • MEG-Array®
    The MEG-Array® Mezzanine Connector system provides the high density and high-speed benefits of a large array supported by the reliability and low costs of standard surface mount PCB assembly.
    DETAILS
  • BergStik® 2.54mm
    BergStik® FCI Basics 2.54mm unshrouded headers are available in surface-mount (SMT), through-hole (THT), press-fit, stacking and pin-in-paste (PIP) versions.
    DETAILS
  • Minitek® 2.00mm
    Minitek® is Amphenol's brand for board to board and wire/cable to board connectors in 2.00mm pitch. It is a fully modular system enabling all types of connections between PCBs, wires and flat cables.
    DETAILS
  • FlexLock® 2.54mm FPC-to-Board Connectors
    FlexLock® 2.54mm FPC-to-Board connectors are designed to address the growing demands of the automotive market.
    DETAILS
  • Minitek MicroSpaceXS™ Waterproof 1.27mm Crimp-to-Wire
    Minitek MicroSpaceXS™ Waterproof Crimp-to-Wire connector platform's unique design is compatible to LV214 Severity-3 and USCAR-T2V2 specifications.
    DETAILS
  • Minitek MicroSpace™ 1.27mm Crimp-to-Wire
    FCI Basics Minitek MicroSpace™ Crimp-to-Wire connector platform's unique design enables LV214 Severity-2 and performs at 1.8, 1.5 and 1.27mm pitch.
    DETAILS
  • Minitek MicroSpace™ 1.50mm Crimp-to-Wire
    FCI Basics Minitek MicroSpace™ Crimp-to-Wire connector platform's unique design enables LV214 Severity-2 and performs at 1.8, 1.5 and 1.27mm pitch.
    DETAILS
  • Minitek MicroSpace™ 1.80mm Crimp-to-Wire
    FCI Basics Minitek MicroSpace™ Crimp-to-Wire connector platform's unique design enables LV214 Severity-2 and performs at 1.8, 1.5 and 1.27mm pitch.
    DETAILS
  • 0.50mm FFC/FPC Connectors with Autolock Mechanism - F308/F332 Series
    F308/F332 series is a 0.50mm pitch right angle Non-ZIF flex connector with an auto lock mechanism and surface mount termination. It features a height of 2.45mm and comes in 6 to 68 contacts.
    DETAILS
  • 0.50mm FFC/FPC Connectors
    Amphenol's 0.50mm pitch flex connectors utilize 0.50mm contact spacing to terminate mobile devices across a variety of applications.
    DETAILS
  • 1.00mm FFC/FPC Connectors
    Amphenol's 1.00mm pitch flex connectors utilize 1.00mm contact spacing to terminate displays and support complex board-to-board connections.
    DETAILS
  • High-Speed Flex Connectors
    FCI Basics High-Speed flex connectors can transfer data rates up to 10Gb/s. It has a 0.30mm pitch, in-line layout and backflip actuator coupled with locking feature for strong FPC retention.
    DETAILS
  • SD Memory Card Connector
    FCI Basics SD Memory Card Connector is tailor-made for the Car Multimedia Device market serving the dashboard and vehicular entertainment applications.
    DETAILS
  • SIM Card Connectors
    FCI Basics SIM Card connectors are 6- to 8-pin connectors primarily used as SIM card readers in smartphones and other mobile devices. These are designed for full SIM, mini SIM, and micro SIM "Plug-in" applications with hinges and covers for secure card retention.
    DETAILS
  • Micro SD and SD Card Sockets
    Micro SD and SD card sockets are user-friendly and ideal for use in portable devices such as digital cameras and mobile phone. They are also suitable for server applications as well as automotive devices, notebooks and Server.
    DETAILS
  • Miniature Jack Connector
    Amphenol's 3.5mm diameter miniature jack connector is a family of connectors used for analog signals, primarily audio.
    DETAILS
  • Waterproof USB Type C
    Waterproof USB Type C with IPX8 performance supports a variety of protocols such as USB 2.0, USB 3.2 Gen 1, USB 3.2 Gen 2 and meet high speed communication and power delivery (20V, 5A).
    DETAILS
  • USB Type C
    USB Type C connectors are expected to be widely used as a next-generation interface. They support a variety of protocols such as USB2.0/3.0/3.1 and meet Superspeed communication 10Gb/s, 5A and 20V power supply.
    DETAILS
  • USB 2.0 Connector
    FCI Basics USB 2.0 connector delivers a data rate of up to 480Mb/s. The Universal Serial Bus interface is ideal for use in connecting removable storage devices into automotive multimedia systems, but extends its functionality to across a variety of domains in consumer, datacom, and industrial applications.
    DETAILS
  • Micro USB 2.0 Connector
    FCI Basics Micro USB 2.0 connectors deliver a data transfer rate up to 480Mb/s and are characterized by their high speed signal stability.
    DETAILS

Body Electronics and Control

Body electronics and control unit of an automotive controls and manages functions of a car such as power seats, door locks, windows, cameras, mirrors and power steering.

Featured Products

  • NETBridge+™ Automotive Ethernet Connector System
    NETBridge+™ Automotive Ethernet Connector System is designed for automotive applications and can transmit up to 100Mb/s and 1Gb/s according to IEEE 100BASE-T1 and 1000BASE-T1 and will be upgraded to 10Gb/s.
    DETAILS
  • HSBridge+ Connector System
    HSBridge+ connectors come with automotive grade USB Type C interface. These connectors have headers compliant to USCAR-30 USB and are performance tested according to USCAR-2.
    DETAILS
  • HSD (High Speed Data) Connector System
    HSD connector system is a fully shielded interconnect system that can be used with shielded twisted quad cables. It has a high-performance digital system for low-voltage differential signals which prevents interference from crosstalk and external sources.
    DETAILS
  • HSC Connector System
    HSC connector system is a fully shielded interconnect system that supports data rates up to 1Gb/s and more. With 0.50mm square terminals, it allows a lighter and smaller connector design.
    DETAILS
  • 0.80mm Floating Board-to-Board Connectors - B406/B407/B410 Series
    Amphenol's B406/B407/B410 series are 0.80mm pitch floating board-to-board connectors which support stack height up to 23mm and positions from 30 to 120.
    DETAILS
  • Minitek MicroSpaceXS™ Waterproof 1.27mm Crimp-to-Wire
    Minitek MicroSpaceXS™ Waterproof Crimp-to-Wire connector platform's unique design is compatible to LV214 Severity-3 and USCAR-T2V2 specifications.
    DETAILS
  • FLTStack 0.50mm Floating Board-to-Board
    FLTStack 0.50mm is a floating type Board-to-Board (BTB) connector designed to operate a minimum of ±0.50mm floating range in the XY directions.
    DETAILS
  • BergStak® FX10 0.50mm Board-to-Board
    FCI Basics BergStak® product range is expanded to include 0.50mm BergStak® FX10 board-to-board connector known for its fast data transmission and high signal quality.
    DETAILS
  • BergStak® 0.50mm Self-Alignment Board-to-Board
    FCI Basics BergStak® 0.50mm self-alignment connectors come with a stack height of 3mm and 50 positions extendable across 20 to 60 positions in increments of 10.
    DETAILS
  • BergStak® 0.40mm Self-Alignment Board-to-Board
    FCI Basics BergStak® 0.40mm self-alignment connectors come with a stack height of 3.50mm and 30 positions extendable up to 10 to 60 positions with 10 positions incremental.
    DETAILS
  • Minitek127® 1.27mm Board-to-Board
    FCI Basics Minitek127® standard board-to-board connector is the improved 1.27mm pitch modular system.
    DETAILS
  • BergStak® 0.80mm Pitch
    FCI Basics BergStak® 0.8mm is a flexible solution designed for high speed and high density, parallel board-to-board connector system with 16 PCB stack heights in 9 sizes up to 200 positions.
    DETAILS
  • MEG-Array® R+
    Leveraging proven technologies, including an industry leading BGA design, offering superior self-aligning and self-leveling.
    DETAILS
  • MEG-Array®
    The MEG-Array® Mezzanine Connector system provides the high density and high-speed benefits of a large array supported by the reliability and low costs of standard surface mount PCB assembly.
    DETAILS
  • BergStik® 2.54mm
    BergStik® FCI Basics 2.54mm unshrouded headers are available in surface-mount (SMT), through-hole (THT), press-fit, stacking and pin-in-paste (PIP) versions.
    DETAILS
  • Minitek® 2.00mm
    Minitek® is Amphenol's brand for board to board and wire/cable to board connectors in 2.00mm pitch. It is a fully modular system enabling all types of connections between PCBs, wires and flat cables.
    DETAILS
  • FlexLock® 2.54mm FPC-to-Board Connectors
    FlexLock® 2.54mm FPC-to-Board connectors are designed to address the growing demands of the automotive market.
    DETAILS
  • Minitek MicroSpace™ 1.27mm Crimp-to-Wire
    FCI Basics Minitek MicroSpace™ Crimp-to-Wire connector platform's unique design enables LV214 Severity-2 and performs at 1.8, 1.5 and 1.27mm pitch.
    DETAILS
  • Minitek MicroSpace™ 1.50mm Crimp-to-Wire
    FCI Basics Minitek MicroSpace™ Crimp-to-Wire connector platform's unique design enables LV214 Severity-2 and performs at 1.8, 1.5 and 1.27mm pitch.
    DETAILS
  • Minitek MicroSpace™ 1.80mm Crimp-to-Wire
    FCI Basics Minitek MicroSpace™ Crimp-to-Wire connector platform's unique design enables LV214 Severity-2 and performs at 1.8, 1.5 and 1.27mm pitch.
    DETAILS
  • SheerPwr® Circular Connectors
    SheerPwr® Circular is a high-current, low-resistance interface, designed for applications connecting busbars -to-busbars, busbars-to-boards and board-to-board configurations.
    DETAILS
  • BarKlip® BK200 I/O
    Amphenol's BarKlip® BK200 I/O provides a convenient method of distributing up to 200A between busbars, cables and circuit boards.
    DETAILS

Battery Management System

The battery is considered as the strategic component of any electric vehicle. All electric vehicles (EVs) are equipped with a Battery Management System (BMS) that intelligently controls the battery charge and protects it from operations beyond the safe limits. It consistently monitors the battery pack during charge and discharge sessions and optimizes the performance by balancing the cells inside the pack, thus improving the battery life and capacity. The accuracy, performance and reliability of the BMS whilst maintaining safety standards is defined by the components used within the system. Amphenol offers a range of compact, flexible high performing automotive grade connectors for these power circuit designs.
Featured Products

Automotive RF Connectors

Automotive Antennas
Can't find what you are looking for?
Contact us

Automotive

Resources

Automotive Standards and Protocols

Amphenol automotive interconnect solutions are developed in accordance with automotive standards and protocols including:
Automotive standards and bodies: High-speed signal protocols such as:
  • USCAR
  • LV214
  • IEEE
  • Open Alliance
  • Low Voltage Differential Signaling (LVDS)
  • Gigabit Video Interface (GVIF)
  • Automotive SerDes Alliance (ASA)
  • Automotive Audio Bus (A2B)
  • DisplayPort
  • Mobile Industry Processor Interface (MIPI)
  • HDBase-T
  • PCIe 4.0
  • USB 2.0
  • USB 3.X
